Dosage reduction program

Through advanced engineering, a Dose Reduction Mode optimizes the intensity of the X-rays which lowers exposure for easily penetrated tissues. Up to 40 % of dosage is reduced compared to the standard mode (for Ø 40 X H 80 mm exposures). By maximizing efficiency, soft tissue, such as the maxillary sinus membrane and skin, appear sharper than ever before with fewer artifacts (Compared to standard exposure mode).

Resolution & Clarity

Veraviewepocs offers high resolution images. It provides clear images of the periodontal pocket, the periodontal ligament, and the alveolar bone. It is extremely useful for implant therapy from planning to post-operative observation.

Short radiation exposure time

With a radiation exposure time of 7.4 seconds for panoramic and just 9.4 seconds for 3D images, the patient is only subjected to X-ray radiation for a brief period.

Panoramic Image with Scout Feature

Before taking a 3D image, a high resolution panoramic exposure can be opened from the existing data base to target the region of interest on the PC monitor. You can select the desired area for the 3D volume rendering image and can activate, by mouse-click, the 3D X-ray image-capture

2-Directional Scout

After initial positioning is accomplished by the 3 positioning laser beams, 2-directional X-ray images can be taken to confirm that the position is accurate. If it is not, simply adjust the position of the image on the computer by placing the cursor at the center of the region of interest.

Direct Positioning with Laser Beams

Positioning laser beams set the patient’s position and align the region of interest. The C-arm will automatically move to the right position.

3D Images for Implant Planning

Successful placement of implants starts with the very critical and detailed planning process. Identifi cation of structures such as the sinus cavity, inferior alveolar nerve and clear views of the bone structure are needed. Veraviewepocs 3D R100 is ideal for implant planning with full arch imaging, industry leading clarity, and low dosage to the patient. The i-Dixel 2.0 software from Morita offers advanced implant planning features, plus compatibility with popular third party software.
With this software you can highlight the mandibular canal for easier viewing, measuring the distance to the implant and determining its buccal and lingual position.

Numerous clinical cases
