The chuck has a strong grip on the bur and is long lasting. The surface of the attachment is durable, corrosion-resistant and more resistant to wear and tear. The surface of the attachment stays clean longer and has a smooth, comfortable feel.

Maximum Illumination

The glass rod light guide minimizes loss of light intensity.

Efficient Spray Filter

The contra angle has a water filter to prevent clogging of the water spray lines. This filter is easily removed for cleaning.

Designation Type no.	CA-5IF-O	CA-DC-O	ST-DH	CA-10RC-ENDO	CA-10RC	CA-10RC-O	CA-4R-PP	CA-4R-O-PF
Model series TorqTech
Transmission ratio	1:5	1:1	1:1	10:1	10:1	10:1	4:1	4:1

Designation Type no.	CA-5IF-O	CA-DC-O	ST-DH	CA-10RC-ENDO	CA-10RC	CA-10RC-O	CA-4R-PP	CA-4R-O-PF
Model series TorqTech
Transmission ratio	1:5	1:1	1:1	10:1	10:1	10:1	4:1	4:1

Designation	CA-5IF-O	CA-DC-O	ST-DH	CA-10RC-ENDO	CA-10RC	CA-10RC-O	CA-4R-PP	CA-4R-O-PF
Model series TorqTech
Max. rpm Transmission ratio	max. 210,000 rpm 1:5	max. 42,000 rpm 1:1	max. 42,000 rpm 1:1	max. 2,000 rpm 10:1	max. 4,200 rpm 10:1	max. 4,200 rpm 10:1	max. 2,500 rpm 4:1	max. 10,500 strokes/ Min. 4:1
Shaft Chuck type Light	FG shaft Ø: 1.6 mm Pushbutton Light guide	RA shaft 2.35 mm Pushbutton Light guide	HP shaft 2.35 mm or RA shaft with spacer No light	RA shaft 2.35 mm Pushbutton No light	RA shaft 2.35 mm Pushbutton No light	RA shaft 2.35 mm Pushbutton Light guide	Screw-in shaft No light	EVA / Laminated shaft Light guide
Application	Preparation	Preparation Prophylaxis	Preparation Prophylaxis Light technical work	Endodontics (only Soaric)	Preparation Endodontics Prophylaxis	Preparation Endodontics Prophylaxis	Prophylaxis	Stripping Debonding Root planing Finishing Prophylaxis
Length \| Weight Head Ø x height	94 mm \| 68 g Ø: 9.5 mm x H: 14.0 mm	94 mm \| 67 g Ø: 9.5 mm x H: 13.3 mm	84 mm \| 72 g –	94 mm \| 55 g Ø: 9.3 mm x H: 12.7 mm	94 mm \| 69 g Ø: 8.0 mm x H: 13.0 mm	94 mm \| 67 g Ø: 8.0 mm x H: 13.0 mm	94 mm \| 67 g Ø: 8.0 mm x H: 8.5 mm	94 mm \| 67 g Ø: 7.8 mm x H: 9.1 mm
Instrument spray	3-hole with spray filter	1-hole with spray filter	1-hole	No spray	1-hole	1-hole with spray filter	No spray	1-hole with spray filter

Designation	CA-5IF-O	CA-DC-O	ST-DH	CA-10RC-ENDO	CA-10RC	CA-10RC-O	CA-4R-PP	CA-4R-O-PF
Model series TorqTech
Max. rpm Transmission ratio	max. 210,000 rpm 1:5	max. 42,000 rpm 1:1	max. 42,000 rpm 1:1	max. 2,000 rpm 10:1	max. 4,200 rpm 10:1	max. 4,200 rpm 10:1	max. 2,500 rpm 4:1	max. 10,500 strokes/ Min. 4:1
Shaft Chuck type Light	FG shaft Ø: 1.6 mm Pushbutton Light guide	RA shaft 2.35 mm Pushbutton Light guide	HP shaft 2.35 mm or RA shaft with spacer No light	RA shaft 2.35 mm Pushbutton No light	RA shaft 2.35 mm Pushbutton No light	RA shaft 2.35 mm Pushbutton Light guide	Screw-in shaft No light	EVA / Laminated shaft Light guide
Application	Preparation	Preparation Prophylaxis	Preparation Prophylaxis Light technical work	Endodontics (only Soaric)	Preparation Endodontics Prophylaxis	Preparation Endodontics Prophylaxis	Prophylaxis	Stripping Debonding Root planing Finishing Prophylaxis
Length \| Weight Head Ø x height	94 mm \| 68 g Ø: 9.5 mm x H: 14.0 mm	94 mm \| 67 g Ø: 9.5 mm x H: 13.3 mm	84 mm \| 72 g –	94 mm \| 55 g Ø: 9.3 mm x H: 12.7 mm	94 mm \| 69 g Ø: 8.0 mm x H: 13.0 mm	94 mm \| 67 g Ø: 8.0 mm x H: 13.0 mm	94 mm \| 67 g Ø: 8.0 mm x H: 8.5 mm	94 mm \| 67 g Ø: 7.8 mm x H: 9.1 mm
Instrument spray	3-hole with spray filter	1-hole with spray filter	1-hole	No spray	1-hole	1-hole with spray filter	No spray	1-hole with spray filter

TorqTech Series
